Shenzhen · Pengcheng Laboratory

Technology as the backbone, rigor as the soul: The facade aesthetics and technological breakthroughs of Pengcheng Laboratory

In 2023, as one of Shenzhen's landmarks of technological innovation, Pengcheng Laboratory made a stunning debut with its architectural temperament of "technology, rigor, and grandeur." This building, carrying cutting-edge scientific research missions, features an exterior curtain wall system meticulously crafted by Aluminum Hero. Through an innovative combination of folded aluminum panels and honeycomb aluminum panels, it not only achieves a minimalist and grand visual expression but also exemplifies the pursuit of performance and quality in scientific research architecture at a technical level.

1. Four Core Considerations in Curtain Wall System Development: Rigor Throughout the Entire Process

The special nature of scientific research buildings requires curtain wall systems to meet stringent standards in safety, performance, adaptability, and sustainability. Aluminum Hero conducted in-depth research and development around the following key dimensions when customizing the curtain wall solution for Pengcheng Laboratory:

Structural Safety and Environmental Adaptation: Shenzhen experiences frequent typhoons and significant temperature differences, so the curtain wall system must first overcome technical bottlenecks related to wind pressure resistance and deformation adaptation. Aluminum Hero uses high-strength profiles, with precise load calculations to ensure the curtain wall can withstand wind pressures with a recurrence interval of 1/100 years and seismic resistance of 7 degrees. The folded aluminum panels' angles are optimized through mechanical simulation to enhance structural stability and impart dynamic tension to the building; honeycomb aluminum panels, with their "lightweight and high strength" characteristics, reduce the main structure load and improve deformation resistance through a composite structure of aluminum core and surface panels, with in-plane deformation capability ≥1/100, perfectly matching the interlayer displacement requirements of the main structure.
Material Performance and Durability Assurance: The choice of curtain wall materials directly affects system lifespan and maintenance costs. Aluminum Hero customizes aluminum panels with fluorocarbon coating processes, with primer, topcoat, and varnish totaling ≥40μm thickness, validated by 2000-hour neutral salt spray tests to resist coastal corrosion. The core material and surface panels of honeycomb aluminum panels are bonded under high temperature and pressure, with double-seal design to achieve water tightness ≥4 and air tightness ≥3, thoroughly eliminating leakage risks. Additionally, over 85% of aluminum alloy materials are recyclable, aligning with sustainable green building concepts.
Energy Efficiency and Integrated Functionality Design: Scientific research buildings demand high energy efficiency and indoor comfort. Aluminum Hero employs material composite technology to embed high-efficiency insulation layers inside honeycomb aluminum panels, effectively reducing heat transfer coefficients (working with Low-E coated glass). The angle design of folded aluminum panels also considers shading functions, optimizing light and shadow refraction paths to reduce solar heat gain, creating a stable temperature and humidity environment for laboratories. Furthermore, the curtain wall system reserves smart sensor interfaces, compatible with temperature and humidity monitoring and adaptive dimming functions, leaving room for future intelligent upgrades.
Aesthetic Expression and Architectural Temperament: Rejecting redundant decoration, simplicity defines grandeur. Aluminum Hero uses large-sized folded aluminum panels to outline the building contours, with clean lines that resonate with the rigorous temperament of the laboratory; honeycomb aluminum panels, with their smooth and delicate surface texture, form a pure and tense building skin through uniform metallic luster and modular splicing. The color choices of both materials are low-saturation metallic tones, presenting a soft yet technological visual effect under different lighting conditions, avoiding excessive flamboyance while highlighting the building's stability as a landmark.

2. Aluminum Hero's Technical Empowerment: Full Chain Control from Materials to Implementation

As the core supplier of the curtain wall system, Aluminum Hero's advantages lie not only in material innovation but also in rigorous control throughout the entire process. During factory prefabrication, precise control of the angles of folded aluminum panels (≤0.5°) and the dimensional accuracy of honeycomb aluminum panels (deviation ≤1mm) ensures efficient on-site assembly; during construction, the installation follows a "vertical truss first, then horizontal beam" logic, with adjustable supports and elastic node designs to accommodate structural deviations and reserve space for thermal deformation.
From compliance verification of material selection, mechanical simulation of structural design, to precision control during construction, Aluminum Hero combines "technology + rigor" to create a curtain wall system that balances aesthetic value and practical performance for Pengcheng Laboratory. The innovative application of folded and honeycomb aluminum panels not only achieves the "simple and grand" design goal but also makes the building's exterior a tangible expression of scientific spirit — just as scientific exploration requires both innovation and rigor, the development of the curtain wall system also reaches new heights in balancing function, aesthetics, safety, and efficiency.
